Product Specification:
Bed Length | 9 Feet |
Height of Centre | 254 mm |
Swing Over Bed | 455 mm |
Product Description:
Heavy Duty Lathe Machines are one of the most extensively utilised lathe machines because of its...Product Specification:
Bed Length | 9 Feet |
Height of Centre | 254 mm |
Swing Over Bed | 455 mm |
Spindle Bore | 52 mm |
Machine Type | Belt Driven Heavy Duty Lathe Machine |
Applicable Industry | Power Plant, Shipbuilding, Oil Industry, Steel Rolling Mills, Textile, Mining |
Bed Width | 325 mm |
Number of Spindle Speeds | 8 |
Distance Between Centre | 1575 mm |
Swing Over Cross Slide | 285 mm |
Maximum Swing in Gap | 775 mm |
Cross Slide Travel | 280 mm |
Spindle Speed Range | 25-500 RPM |
Lead Screw Diameter | 38 mm |
Lead Screw Pitch | 4 T.P.I |
Tail Stock Spindle Diameter | 52 mm |
Tail Stock Spindle Taper Bore | MT-4 |
Tail Stock Spindle Travel | 190 mm |
Motor Power | 2 HP |
Range of Inch Thread | 4-24 T.P.I |
Range of Metric Thread | 1-6 mm |
Product Description:
Heavy Duty Lathe Machines are one of the most extensively utilised lathe machines because of its high quality and rapid rate of output. These are made of high-quality iron and steel and are built to withstand the most difficult shaping chores. They are particularly well suited to high-volume production because to their high-performance capacity to work at fast speeds.
We deal in all types of V-Belt Type/Driven Light, Medium, Heavy Duty & Extra Heavy Duty Lathe Machines.
