Elak Mark-II Auto Electrical Test Bench

Brand: Elak Private Limited

90,000 / 25 pieces

Product Specification:

Connection Type	Starter Test Free Run upto 200 Amps (with external batteries)
Power Source	Electric
Voltage	230 V

Product Description:

Elak MarkII Auto Electrical Test Bench is a table model and has been designed to cater to the needs...

View Complete Details

Product Details
Company Details

Product Specification:

Connection Type	Starter Test Free Run upto 200 Amps (with external batteries)
Power Source	Electric
Voltage	230 V
Frequency	50 Hz
Dimension	520 x 620 x 720 mm
Weight	83 kg
Brand	Elak
Regulator Tester Voltage	12 or 24 V
Alternator Warning Light Voltage	12 / 24 V
Alternator Load	12 V (Max 75 A),24 V (Max 70 A)
Phase	Single Phase
Table Working Area	320 x 360 mm
Inbuilt DC Power Supply	12 - 24 V

Product Description:

Elak MarkII Auto Electrical Test Bench is a table model and has been designed to cater to the needs of Auto Electricians Garages Services Centers Transport Corporations Educational Institutions and other bulk users of Auto Electrical Equipments for complete testing of Alternator Regulator and their associated parts Provision for testing Starter Motors using external battery This userfriendly hitech test bench is divided into two sections For testing Alternators For testing Starter Motors Instrumentation Ampere Meter Digital Panel Meter 0 200 Amps Volt Meter Digital Panel Meter 0 200 Volts Drive 2 HP 15 KW Single Phase Motor with 2 Step Pulley Overload protected with circuit breaker Mark II Features Vice Heavy duty Fast mounting vice for Alternators and Starters Maximum dia of device under test 175 mm Easy Transportation Bench top model Fixed 12 24 V 5 Amp field supply Starter Test Free Run upto 200 Amps with external batteries Full set of test leads Working area covered with a rubber mat Separate digital meters for Alternator Starter Tests A 110 V series lamp for insulation test Additional Information Item Code MarkII
