Product Specification:
Model Name/Number | ESH-18 |
Driven Type | Electric |
Length Of Ram Stroke | 450 mm |
Product Description:
Shaper machines can be classified as follows :Standard shaper machinesDraw-cut shaper...Product Specification:
Model Name/Number | ESH-18 |
Driven Type | Electric |
Length Of Ram Stroke | 450 mm |
Motor Speed | 1440 RPM |
Working Surface Of Table | 457 X 305 mm |
Length of Ram | 960 mm |
Motor Power | 2 HP |
Distance From Table To Ram | 360 / 75 mm |
Horizontal Table Travel Max | 488 mm |
Vertical Table Travel Max | 330 mm |
Swivel Of Tool Head Max | 60 L / 60 R mm |
Diameter Of Clutch Pulley | 311 mm |
Motor Pulley Diameter | 70 mm |
Country of Origin | Made in India |
Product Description:
Shaper machines can be classified as follows :
Standard shaper machines
Draw-cut shaper machines
Horizontal shaper machines
Universal shaper machines
Vertical shaper machines
Geared shaper machines
Crank shaper machines
Hydraulic shaper machines
Contour shaper machines
The horizontal shaper machine is the most common shaper machine. Vertical shaper machines are normaly fitted with a rotary table to enable curved surfaces to be machined. The vertical shaper machine is almost same thing as a slotting machine. A vertical shaper is a machine, whose slide can be moved from the vertical. A slotter machine is fixed in the vertical plane. Small shaper machine can be operated by hand power. But, as size of the machine increases, the mass of the machine and its power requirements also increase. Then the use of a motor or other supply of mechanical power becomes essential to operate it. We manufacture and sell all type of shaper machines including all geared shaper machines.
Specification Of Esskay Brand Shaper Machine
MODELESH-12ESH-18ESH-24ESH-30ESH-36ESH-42Length of ram stroke:12" / 305 mm18" / 457 mm24" / 610 mm30" / 762 mm36" / 915 mm42" / 1070 mm.Length of ram (mm):7119601232141016512108Length x Width of Ram bearing (mm):724 x 203700 x 270867 x 3001020 x 3301130 x 3301600 x 330Distance from Table to Ram Max / Min (mm):257 / 41360 / 75450 / 76510 / 75565 / 102600 / 102Working Surface of table (mm):305 x 228457 x 305610 x 370762 x 390915 x 4571078 x 533Horizontal Table Travel Max (mm):3304886357879401075
