Product Specification:
Brand | ELGi |
Compressor Technology | Screw Compressor |
Model Name/Number | EE132 |
Product Description:
Elgi offers Two Stage Horizon Series Screw Air Compressors to help industries reduce their...Product Specification:
Brand | ELGi |
Compressor Technology | Screw Compressor |
Model Name/Number | EE132 |
Weight | 3700 kg |
Working Pressure | 7 Bar g |
Free Air Delivery | 27.3 m3/hr / 965 cfm |
Dimensions | 3400x1620x1972 mm (LxBxH) |
Product Description:
Elgi offers Two Stage Horizon Series Screw Air Compressors to help industries reduce their operating and energy costs. It is a two-stage compressor, having energy efficiency as the key feature. The compression is done in two-stages to improve the volumetric efficiency and thereby contributing to decrease in power consumption and increase in saving energy costs. Tandem air compressors consume 8-12% less power and offer a return on investment within 8-15 months when compared to single-stage compressors
A single-stage compressor , operating at a discharge pressure of 9 bar, has a compression ratio of 1:9 (Ratio of Suction to Discharge of a Screw Air end) . In a two-stage compressor operating at the same discharge pressure, the compression ratio is divided between the two stages of tandem air end and is about 1:3 in each stage . This makes the air end more reliable and efficient due to smaller loads on the bearings. The volumetric efficiency of two-stage is better than single - stage compression.
