Product Description:
“INGECO” IPH Series Helical Speed Reducers is the modern development and designed specially for use on systems for SINGLE SCREW EXTRUSION of various materials such as plastic and rubber. It is also widely used in Plastic Blow Molding Machines. "INGECO" IPH Series two stage Helical Reducers have modular design with a normal reduction ratio ranging between 10:1 and 15:1. The single piece close gain C.I. Casting gives a rigid robust construction and incorporates high precision Case Hardened and Ground Helical Gear Train for improved Torque Transmission.
“INGECO” IPH Series reducers are available in 8 sizes suited for upto 100 Kw. and screw diameters of upto to 150 mm. Our Extruder gearboxes are designed for maximum screw pressures. The Spherical Thrust Bearing / Taper Roller Bearing system carries reverse thrust load generated by differential pressure during moulding. Process.
Important features of this design
Rigid Single Piece Thrust Housing
Spherical Thrust / Taper Roller Bearing
Dual output shaft oil seals for severe continuous duty applications
Gear ratio of 10:1, 12.5 and 15:1 and power rating upto 100 Kw
Water cooling option available which is In-built
