Product Description:
In order to withstand wide voltage fluctuations vacuum pumps are designed with an impeller of high quality of bronze material. These pumps are designed to prevent overloading and motor burning. These pumps come with sturdy casing, provided with foot, suction and delivery nozzles. Widely used in priming of large pumps, extrusion machines, printing machines and so on.
Specifications:
Vacuum up to 650 mm of Mercury
Air flow rate up to 55 m3 /hr
Power rating 0.75 kW to 2.2 kW (1 hp to 2 hp)
Features:
Can withstand wide voltage fluctuations. From 180 to 240 Volts for single phase From 300 to 440 Volts for three phase
Models are with ‘B' class of insulation and IP 44 protection. Models in three phase A.C. power supply can be supplied with IP-55 protection on request.
Designed to prevent overloading and motor burning.
Long life - Due to replaceable wearing parts.
Dynamically balanced rotating parts ensure minimum vibrations.
Easy maintenance and spares availability.
Applications:
Priming of large pumps.
Evacuation of air from suction pipes and chambers.
General Applications : Drying, Evaporation, Distillation, Filtration,Sterilisation, Condensation Degasification, Sucking gases.
Specific applications : Twist Drilling Machine, Removing water from pulp layer, labeling, Bottle filling De-odorising.
Range:
Vacuum : Up to 650 mm of Mercury.
Air Flow Rate : Up to 55 cubic metres per hour.
Power Rating : 0.75 kW and 2.2 kW (1.0 HP and 3.0 HP)
Direction of Rotation:
Anti-clockwise, when viewed from pump side.
Material of Construction:
Standard Supply
Rotor (Impeller) : Bronze
Delivery casing : Cast Iron
Motor : Cast Iron
Shaft : Carbon Steel
To view More Details, Please download attached PDF.
Additional Information
Item Code Kirloskar-KV
