Plastic Strapping Combination Tool

Brand: Penumatic Power Tools & Co. Pvt. Ltd.

Ask For Price

Product Specification:

Strap width	13 – 19 mm / 0.51”- 0.74”
Strap thickness	0.5 -1.5 mm / 0.02” – 0.06”
Grade	PET/PP

Product Description:

We are indulged in offering an excellent quality range of Plastic Strapping Combination Tool at...

View Complete Details

Product Details
Company Details

Product Specification:

Strap width	13 – 19 mm / 0.51”- 0.74”
Strap thickness	0.5 -1.5 mm / 0.02” – 0.06”
Grade	PET/PP
Air pressure	5.0 to 7.0 kg/cm2.
Tool Weight	4.0 Kg / 8.88 lb
Dimension (L X W X H)	280 x 160 x 180 mm / 11” x 6.3”x7.1”
Range of Adjustment for welding time	2 – 4.5 Sec.

Product Description:

We are indulged in offering an excellent quality range of Plastic Strapping Combination Tool at industry leading price.

Features:

Medium duty Plastic Strapping Combination Tool
Tensioning, cutting & friction welding done in one setting
Light in weight makes it perfectly handy
Easy to operate & maintain
Maximum Tension: 3000N
Heavy duty moving & stationary cutter fitted to cut the strap of thickness from 0.5 - 1.5 mm thick
Friction welding done by pressing orange lever
Used for stationary operation, we can seal strap in Horizontal & vertical position by using proper tool hanger
Inserting of the strap into the tool is easier
Widely used in different industries for different application
We can adjust the strap tension & vibration welding time easily for different size of strap and volume of air supply

Operational Manual:

Check the Pneumatic hose and FRL in the air line. Air motor should be properly lubricated
Check the strap before start the operation
Positioning the strap around the material and hold the overlap portion
Pull out the excess strap for next operation
Insert upper & lower strap together in the tool by holding the handle and Tensioner
Release the Tensioner
Press the Tensioning lever until the strap is fully tensioned
Press the vibration lever for cutting the mother strap and friction welding and it will stopped automatically
Remove the tool by squeezing the reverse lever of the tool

Safety Instructions:

Only trained person should operate the tool
Wear, Helmets, safety shoe, goggles at the time of operation
Use proper tool for right application
Do not put hands between the strap and material
Lubricate the tool time to time
