Product Description:
In our extensive product range, we are highly engaged to manufacture a quality approved range of Shaft Mounted Speed Reducers Gearbox.
Description:
Shaft Mounted Speed Reducer provides a very convenient method of reducing speed, since it is mounted directly on the driven shaft instead of requiring foundations of its own. It eliminates the use of one, and sometimes two, flexible couplings and (2) external belt take-up arrangement.
A very wide choice of final driven speed can be determined by the use of an appropriate input V-Belt drive, The units will normally be oil lubricated, but they are equally suitable for "lubricated for life" greases.
Shaft Mounted Speed Reducer consists of hardened precision-machined alloy steel Helical Gears mounted on micro finish Shafts supported on long life precision bearings with the capacity to handle maximum loading. The two pieces close Grain C. I. housing provides sturdy support and insures permanent accurate alignment of all components.
Dimensions Of Shaft Mounted Speed Reducer
SIZE H W D ØG L ØB M J K Approx Weight (Kg)
Min. Max. 5:1 13-20 ratio
A 208 160 117 14 51 30 70 200 600 750 10 11
B 226 186 134 19 63 30 79 200 600 750 15 16
C 285 230 145 22 72 40 95 200 600 750 21 22
D 365 258 165 25 74 50 117 216 700 850 30 32
E 377 278 170 28 85 55 133 216 700 850 41 46
Features:
High strength
Corrosion resistance
Optimum finish
