| Engine Power |
125 PS 2250 |
| Brand |
TATA |
| Engine Type |
Spark Ignition |
| Maximum Torque |
420 Nm 1500-1800rpm |
| Battery |
12 v - 100 Ah |
| Fuel Tank Capacity |
396l & 486l Water Capacity |
| Wheelbase |
4200 / 4830 Mm |
| Gradeability |
25.0% |
| Cabin |
Day Cab |
| Engine |
3.8 Sgi Tc Bs6 Engine |
| Engine Displacement (cc) |
3783 |
| Clutch |
Single Plate Dry Friction Type - 330 Mm |
| Gear Box |
Gbs 40 Gear Box (5f,1r),Mechanical Linkage Road Shifting |
| Rear Axle Ratio |
Tata Ra 1109 Fully Floating Benjo Axle (Rar - 5.285) |
| Brake Type |
Dual Circuit Full Air S" Cam Brakes With Auto Slack Adjuster (Drum - Drum) And Abs |
| Steering type |
Tilt & Telescope Power Steering (Dia - 426mm) |
| Ground Clearance |
225mm |
| Front Type |
Parabolic Leaf Spring With Hydraulic Double Acting Telescopic Shock Absorbers |
| Rear Type |
Semi-Elliptical Leaf Spring |
| Tyres |
8.25r 20-16pr Radial |
| GVW |
13850 Kg |
| FAW |
4750 |
| RAW |
9100 |
| Warranty |
3 Years/ 3 Lakhs Km |
| Seating capacity |
D+1 |
| Seating capacity |
223mm x 60mm x 7mm |
| Variants |
Cab,Clb/Fsd,Hsd,Containers,Reefers |
| Load Body Dimenssions (mm) (LxWxH) |
6095 x 2175 x 1830 / 6795 x 2175 x 1825 |
