TATA 609g SFC BS6 Truck

Brand: Tata Motors Limited
Ask For Price

Product Specification:

Alternator Vaccum assisted- H2LS ; Auto Slack Adjuster
Clutch Single plate dry friction type- 280 mm dia
Cabin All Steel SFC Cabin

Product Description:

In Line with the ‘Clean Fuel Corridor’ being created by the government across India...
View Complete Details
  • Product Details
  • Company Details

Product Specification:

Alternator Vaccum assisted- H2LS ; Auto Slack Adjuster
Clutch Single plate dry friction type- 280 mm dia
Cabin All Steel SFC Cabin
brand TATA
Deck Length 10FT
Displacement/ Cubic capacity 3783 cc
GVW (in Kg) 5950 kg
Maximum Power Output (in Kw) 85PS @ 2500 r/m
Minimum Ground Clearance(in mm ) 249
Minimum Turning Dia (in metres ) 13.1
No. Of Tyres 8.25-16 16PRR,Front 2,Rear 2,Spare
Steering System Power Steering
Emission Compliances BS6
Gradeability 23.00%
Wheelbase 3305MM
Transmission G400,5 Speed Manual Synchromesh Gearbox (5F,1R) PTOP
Fuel Tank Capacity 180 liters (2 x 90 Litres)
Model Name/Number 609g SFC
Rear Suspension Semi elliptical leaf spring and 2 no Hydraulic double acting telescopic type Shock Absorber
Maximum Torque 285 Nm @ 1200-1600 r/m
Front Suspension Parabolic springs and 2 no Hydraulic double acting telescopic type shock absorbers with Antiroll Bar
Engine Type 3.8 SGI BS6

Product Description:

In Line with the ‘Clean Fuel Corridor’ being created by the government across India starting from the northern belt Tata Motors proudly presents its new ‘Green Range’ of BS6 CNG TrucksThe Legend of trucking the prestigious SFC 407 Ex CNG returns in an all new avatar as The TATA 609g SFC CNGTaking pride as the truck with “The Best value for money LCV Truck” the 609g SFC has much to offer with it’s Improved product and driver packages enhanced connectivity and Gradeability lower cost of ownership thus making it the most desired CNG LCV in IndiaIn addition Tata Motors is the ONLY manufacturer in India selling the SFC Styled Cabins with the ‘Unique NOSE’ for highest levels of safetyThis truck has won the hearts of the Owners and Drivers alike and if you’re looking out for a 6 Ton Cargo Truck with a 10 Ft Deck length this truck is yours to ownThis future-ready trucks cater to all the applications in the LCV segment with trusted Tata 38 SGI CNG BS6 Engine and reliable aggregates you can be assured of the best return on investment for your businessOur latest Exhaust system offers a reduction in the tail pipe emissions by 95% 50% lesser running cost 30% lesser green house gases and 20% lesser knockingThe top feature upgradations done in this BS6 CNG range vehicle are: improved package of Power Torque and low end Torque improved GVW and Payload higher gradeability standard Power steering with new design improved H2LS Braking Banjo Type Rear Axle improved chassis thickness reduction in clutching and Gear shifting efforts Parabolic Suspension in Front Music System with Blaupunkt speakers USB fast Charging New Seat design with heat resistant Melba Fabric PTO Provision reverse parking assist Etc








LOAD BODY DIMENSIONS



Load body Length (in mm )
Load body Width (in mm )
Load body Height (in mm)
CBC FSD HDLB
NA 3071 (10.07 Ft) 3071 (10.07 Ft)
NA 1965 (6.44 Ft) 1965 (6.44 Ft)
NA 450(1.47 Ft) 1835 ( 6.02 Ft)
OVERALL DIMENSIONS

OVERALL LENGTH (in mm)
Overall Height (in mm)
Overall Width (in mm)
CBC FSD HDLB
5407 5412 5412
2380 2380 2959
1905 2100 2100

Company Description :

Tata Motors Ltd. - Manufacturer of automobile parts, job work of automobile parts & automobile pipes in Kolkata, West Bengal.

  • Website Url: www.tatamotors.com
  • GST No. : 19AAACT2727Q1ZT
  • Address : 15,Apeejay House,Block C,5th Flr, Park St,, Park Street, Kolkata - 700016, Kolkata-700016, West Bengal, India
