| Engine Power |
125 Ps @2600 |
| Brand |
TATA |
| Engine Type |
4 Cylinder in line water cooled direct Injection diesel engine with intercooler |
| Maximum Torque |
390 Nm @ 1000-2200 rpm |
| Battery |
12 V - 100 Ah |
| Front Suspension |
Semi-Elliptical leaf spring with Hydraulic Double acting Telescopic Shock Absorbers |
| Rear Suspension |
Semi-Elliptical Leaf Spring |
| Fuel Tank Capacity |
120L |
| Tyre Specification |
7.5R16 -16PR (FR-2, RR-4, Spare -1) |
| Wheelbase |
3400 / 3800 mm |
| Gradeability |
29.2% |
| Cabin |
Day Cab |
| Engine Displacement (cc) |
3300 |
| Clutch |
Single Plate Dry Friction Type, 310 mm |
| Gear Box |
GBS 40 Gear Box (5F, 1R) |
| Rear Axle Ratio |
TATA RA 1068 Fully Floating Benjo Axle (RAR - 4.42) |
| Brake Type |
Dual Circuit Full Air S |
| Steering |
Tilt & Telescope Power Steering (Dia - 426mm) |
| Ground Clearance (mm) |
193 mm |
| GVW (in kg) |
8750 |
| FAW |
3190 |
| RAW |
5560 |
| Variants |
CAB, CLB/FSD, HSD |
| Long member Size (mm) (LxBxH) |
200mm x 60mm x 5mm |
| Seating Capacity |
D+1 |
| Warranty |
3 years/ 3 Lakhs km |
| Load Body Dimenssions (mm) (LxWxH) |
4347 x 2117 x 1835 / 5217 x 2117 x 1835 |
| Deck Length |
4347mm (14ft) / 5217 mm (17ft) |
