Product Description:
Tractor Dozer Hydraulic Cylinder offered comprise high performance based farm tractor loader...Product Description:
Tractor Dozer Hydraulic Cylinder offered comprise high performance based farm tractor loader hydraulic cylinders that find application in areas like mechanical equipment, marine equipment, mining equipment and others. Further, these hydraulic cylinders can be made available in work length from 50mm to 16000mm with bore support of 40mm to 1000mm and rod options of 12mm to 500mm. Some of its features include can handle work pressure of 70bar to 700bar; superior seal support for lasting performance; offering optimum operating efficiency and performance; provide for stable and reliable quality performance; offering high transmission efficiency and long service life. (1) Trunion Type Cylinder For Center Fitting :
Dimension | Inch | mm |
Close Center | 10" | 254 |
Open Center | 32" | 812.8 |
Stock | 22" | 595 |
Rod dia | 50mm | |
Rod pin Hole | 40mm | |
Trunion pin Dia | 40mm | |
Body tube | 88mm x 75mm |
(2) Center Fitting Trunion type :
Dimension | Inch | mm |
Close Center | 34 | 863 |
Open Center | 17.75 | 451 |
Stock | 16.25 | 413 |
Rod dia | 40mm | |
Rod pin Hole | 40mm | |
Trunion pin Dia | 40mm | |
Body tube | 88mm x 72mm |
(3) Side Fitting Cylinder (Pair) :
Dimension | Inch | mm |
Close Center | 23.5 | 597 |
Open Center | 34.5 | 876 |
Stock | 11 | 280 |
Rod pin Hole | 25.4mm | |
Rod dia | 30mm |
