Product Description:
The compound rest (or top slide) (2) is usually where the tool post is mounted. It provides a smaller amount of movement (less than the cross-slide) along its axis via another feedscrew. The compound rest axis can be adjusted independently of the carriage or cross-slide. It is used for turning tapers, to control depth of cut when screwcutting or precision facing, or to obtain finer feeds (under manual control) than the feed shaft permits. Usually, the compound rest has a protractor marked in its base (2b), enabling the operator to adjust its axis to precise angles.
The terms center lathe, engine lathe, and bench lathe all refer to a basic type of lathe that may be considered the archetypical class of metalworking lathe most often used by the general machinist or machining hobbyist. The name bench lathe implies a version of this class small enough to be mounted on a workbench (but still full-featured, and larger than mini-lathes or micro-lathes). The construction of a center lathe is detailed above, but depending on the year of manufacture, size, price range or desired features, even these lathes can vary widely between models.
Standard Accessories:
Flame Hardened Bed Ways, chucK Plate 1 no. Centre Adapter, Dead Centres MT-3, 2 NOS, Tool Post Spanner, Motor Pulley, thread Dial Indicator, Chip tray, Change Gear Set-1 (For Metric and Inch both)
Optional Accessores:
Face Plate, Carrier Plate, Steady rest, Follow Rest, Taper Turning Attachment, motorised coolant pump with tank and fittings, Rear Tool Post with extended cross slide, Norton Gear Box, Chuck back plates (extra), electcricals (Motor, Switch, wiring, v-belts and fittings)
Additional Information:
- Item Code: KM-2-250-50
- Pay Mode Terms: T/T (Bank Transfer)
- Port of Dispatch: NAVA SHAVA
- Production Capacity: 30
- Delivery Time: 1 WEEK
- Packaging Details: 1650 X 970
